16.8v Dc Electric Motors 775 Motor 24000rpm Replacements Power Wheels

• Internal Winding: 10 turns per armature • Shape of Motor Housing: Round
• Type of Motor: Carbon Brushes
• Construction: Anisotropic Magnet or Rare Earth Magnet
• Optimal Voltage:: 16.8 volts
• Operating Voltage Range: ~12v - 24v

Unloaded (free spinning):
• No Load RPM: 24300
• No Load Current: 3A

Stalled (max load):
• Stall Torque: 860.587 mN.m
• Stall Current: 119.45 amps

At Maximum Effic.:
• Max Effic. Percent: ~80% • Max Effic. Torque: 121.90 mN.m
• Max Effic. RPMs: 21012
• Max Effic. Current: 19.17 amps
• Max Effic. Output Power: 268.4 Watts

At Maximum Output Power:
• Max Output Power Effic. Percent: 54.39% • Max Output Power Torque: 121.90 mN.m
• Max Output Power RPMs: 12150
• Max Output Power Current: 62.754 amps
• Max Output Power: 573.488 Watts


Dimensions:
• Motor Body Length: 2.62in (66.7mm)
• Motor Body Diameter: 1.75in (44.7mm)
• Weight: ~12.9oz (366g)
• Mounting holes (2): M4
• Mounting Holes: 29mm apart
• Shaft Diameter: 5mm
• Shaft Style: Round
• Shaft Length: 13.5mm (~9.5mm usable exposed)



Designed as a replacement for Titan 775 Motor for use in Traxxas 5675
Also suitable for hobby, DIY, and repair/replacement applications such as in Power Tools, Drills, and other cordless outdoor tools.
As well as a popular choice for Do-it-Yourself choice for Electronics projects, Robotics, Power Wheels, Gate Openers, and More. Fit your existing gear or pinion for your application for 1000s of uses

***PLEASE NOTE:Will not work or fit in all models, be sure to check your specific application's requirements or contact us before purchasing. If you're replacing a motor please be sure to verify the motor matches the specifications and sizes listed above.
